Note: This is a B2B Product
-Prices are indicative and discounts available based on quantities
-Design services available for these systems. Please contact our team for support on , or .
FEATURES:
- 6 Mic & 2 Aux Inputs.
- Built-in digital effect processor for 2 Mic Inputs.
- Preamplifier and Line Output for connecting to a Booster Amplifier and for recording the program
- Line Input for connecting the output from any external mixer or permitting SSA-250®M to be used as a Booster Power Amplifier.
- Resettable circuit breaker for protection against overload and short circuit. Instant transfer to DC power (Car Battery) if AC power fails.
- Box Speaker/Driver Unit selector switch. Bass boost defeated at Driver Unit position for safer operation of driver units
SPECIFICATIONS:
Power Output | 300W Max., 250W RMS at 10% THD 220W RMS at 5% THD, 200W RMS at 2% THD |
Output Regulation | ≤ 2 dB, no load to full load at 1kHz |
Input Channels | 6×Mic 0.65mV/4.7kΩ, 2×Aux 100mV/470 kΩ, 1 × Line 1V/50kΩ |
Delay System | Digital Signal Processing |
Delay Range Setting | 60-300ms |
Frequency Response | 50-15,000Hz ±3dB |
Signal to Noise Ratio | 60dB |
Tone Controls | Bass: ±10dB at 100Hz, Treble: ±10dB at 10kHz |
Outputs | Preamp 200mV/600Ω, Line 1V/1kΩ |
Speaker Outputs | 4Ω, 8Ω, 70V & 100V |
Power Supply | AC: 220-240V 50/60Hz DC: 24V (2×12V Car Battery) |
Power Consumption | AC: 460VA DC: 6A |
Dimensions | W450 × H160 × D340 mm |
Weight | 15.70kg |
